Korporate 3000 Series

Studform's Series 3000 partition suite was developed to maintain a high-profile corporate appearance at doorways and openings within highly rated acoustic walling – holding a quality profile throughout even with a cavity of up to 92mm.

Featuring the capacity to fully contain column supports for overhead structures within the partition system itself, the Series 3000 gives architects and engineers a unique range of options, combining structural integrity with high acoustic performance in a single system.

Typical applications:

  • Highly rated acoustic walling: 92mm stud with 2 layers of 13mm plasterboard, 76mm stud with 3 layers, or 64mm stud with 4 layers.
  • Structural column walling: Accommodates mezzanine and other structural supports at 90 x 90mm or 120 x 90mm.

The Korporate 3000 Series is ideal for high acoustic applications across  commercial spaces, office fit-outs, and education facilities.

Korporate Series Aluminium Partition Systems - 3000 Suite - Natural Anodised


 Part Number Description Length
K3001NA Main/Door Frame 5500mm
K3002NA
 Sill Transom 5500mm
K3003NA Sill Bead 5500mm
K3004NA Glazing Adaptor 5500mm

K3005NA Ceiling Frame Adaptor 5500mm
K3011NA
 Shadowline Ceiling Channel 5500mm



Door Stops / Pocket Fillers – Suitable for all Korporate Series


 Part Number Description Length

K1012NA Pocket Filler 5500mm

K1013NA 35mm Door Stop 5500mm
K1014NA 45mm Door Stop 5500mm
K1015NA 40mm Door Stop 5500mm
K1016NA 55mm Door Stop / 45mm Acoustic Door Stop 5500mm

K1017NA
 42mm Door Stop 5500mm


Korporate Series Aluminium Partition Systems - 3000 Suite - Powdercoated


 Part Number Description Length
K3001PC Main/Door Frame 5500mm
K3002PC
 Sill Transom 5500mm
K3003PC Sill Bead 5500mm
K3004PC Glazing Adaptor 5500mm

K3005PC Ceiling Frame Adaptor 5500mm
K3011PC
 Shadowline Ceiling Channel 5500mm



Door Stops / Pocket Fillers – Suitable for all Korporate Series


 Part Number Description Length

K1012PC Pocket Filler 5500mm

K1013PC 35mm Door Stop 5500mm
K1014PC 45mm Door Stop 5500mm
K1015PC 40mm Door Stop 5500mm
K1016PC 55mm Door Stop / 45mm Acoustic Door Stop 5500mm

K1017PC
 42mm Door Stop 5500mm



Aluminium Skirting and Accessories


 Part Number Description Length

1026NA Aluminium skirting 100mm Adhesive fix Natural Anodised 3600

1028NA Aluminium skirting 150mm Adhesive fix Natural Anodised 3600
ANBL10 Anodising Block 1/PK NA
64DJ K1000 Series Drilling Jig 1/PK NA
1020B Schlegel Wool Pile - Black 100m
1020G Schlegel Wool Pile - Grey 100m
1021 Semi- Acoustic Door Seal 100m

1024 Glazing Support Block 10 x 12mm 500/PK
CFP100 Self Adhesive Carpet Floor Protection Roll 100m 100m

CCS Korporate Series Ceiling Channel Corner Stakes

CSS Korporate Series Channel Straight Stakes
MSS Korporate Series Main Frame Straight Stakes
MCS Korporate Series Main Frame Corner Stakes



Powder-coating colour options: Almond Ivory, Anodic Bronze, Apo Grey Satin, Arrowhead, Berry Grey, Black Gloss, Black Matt, Black Onyx Pearl, Black Satin, Bright White, Charcoal, Charcoal Matt Pearl, Claret Satin, Cool White, Doeskin Satin, Federation Red, Hamersley Brown, Satin, Hawthorn Green, Ivory Coast, Magnolia, Notre Dame, Mother of Pearl, Olde Pewter Satin, Oyster Grey, Pearl White, Pottery Satin, Primrose, Rivergum, Roseberry Grey, Stone Beige Satin, Silver Glo Pearl, Stromboll, Transformer Grey, White Birch, White Satin.

Ready to Specify the Korporate 3000 Series for your next project?

Access specification tools or contact our Project team

Specify Now

Features of the Korporate Partition Suite

The Korporate Partition Suite is a complete office partition system designed to enhance the appearance and performance of the modern office interior. Designed for architects, builders and contractors, it covers every stage of a project – from design through to construction with Centreline, Frontline and Double glazing options across 64mm, 76mm and 92mm steel stud framing clad with 13mm plasterboard.

  • Profile & glazing: A consistent 36mm profile accommodates glass up to 12.38mm, keeping sightlines clean without adding bulk.
  • Glazing detail: Recessed wedges reduce visibility for a cleaner finish, with corner stake provision for stronger junctions.
  • Acoustic performance: Achieves acoustic walls of up to STC48.
  • Finish: Radiused edges and shot blast aluminium combine for a refined appearance, ready for anodising.
  • Installation support: Drilling jigs and an optional fabrication service help contractors move faster on site.
  • Stock availability: Ex-stock in 5500mm lengths, with custom lengths available for special projects to minimise wastage.

Studform also offers specialist design support, drawing on decades of experience coordinating ceiling systems, lighting and building services to help deliver compliant, efficient and buildable project outcomes.

Studform supplies everything needed to deliver a project – steel studs, plasterboard, insulation, doors and hardware. The system is constantly evolving, with new sections in development. For specific design support, get in touch with our team.
