Korporate 1000 Series

Studform's Korporate 1000 Series is a cost-efficient, aesthetic partition system engineered for the modern work environment, combining a slimline 36mm profile designed and manufactured in accordance to AS 1288:2021 – Glass in buildings.

Featuring extrusions designed to eliminate unsightly vertical join lines, corner stake provision, screw locating grooves and alignment fins that automatically centre studwork, the system delivers a clean, seamless finish and faster on-site installation. A full extrusion range covers almost any application though most standard installs need just four to five sections.

Designed for use with 64mm steel stud and two layers of 13mm plasterboard or a 51mm offset configuration with two layers to one side and one to the other for increased acoustic performance – the Korporate 1000 Series keeps partition costs economical. It accommodates 35mm, 40mm, 42mm and 55mm doors in timber or fully glazed aluminium, supplied if required.

The Korporate 1000 Series is ideal for commercial spaces, office fit-outs, and education facilities.

Korporate Series Aluminium Partition Systems - 1000 Suite - Natural Anodised


 Part Number Description Length
K1000NA Main Frame  5500mm
K1001NA Main-Door Frame 5500mm
K1002NA Still Transform 5500mm
K1003NA Still Bead  5500mm
K1004NA Glazing Adaptor  5500mm

K1005NA
 Ceiling Frame Adaptor  5500mm
K1009NA Plain/Door Frame  5500mm
K1010NA Standard Ceiling Channel  5500mm
K1011NA Shadowline Ceiling Channel 5500mm


Door Stops / Pocket Fillers – Suitable for all Korporate Series


 Part Number Description Length

K1012NA Pocket Filler 5500mm

K1013NA 35mm Door Stop 5500mm
K1014NA 45mm Door Stop 5500mm
K1015NA 40mm Door Stop 5500mm
K1016NA 55mm Door Stop / 45mm Acoustic Door Stop 5500mm

K1017NA
 42mm Door Stop 5500mm



Perforated Section For Flush Slimline Finish


 Part Number Description Length
K1011F 64mm Headtrack Perforated P50 Finish 3600mm



Korporate Series Aluminium Partition Systems - 1000 Suite - Powdercoated


 Part Number Description Length
K1000PC Main Frame  5500mm
K1001PC Main-Door Frame 5500mm
K1002PC Still Transform 5500mm
K1003PC Still Bead  5500mm
K1004PC Glazing Adaptor  5500mm

K1005PC
 Ceiling Frame Adaptor  5500mm
K1009PC Plain/Door Frame  5500mm
K1010PC Standard Ceiling Channel  5500mm
K1011PC Shadowline Ceiling Channel 5500mm


Door Stops / Pocket Fillers – Suitable for all Korporate Series


 Part Number Description Length

K1012PC Pocket Filler 5500mm

K1013PC 35mm Door Stop 5500mm
K1014PC 45mm Door Stop 5500mm
K1015PC 40mm Door Stop 5500mm
K1016PC 55mm Door Stop / 45mm Acoustic Door Stop 5500mm

K1017PC
 42mm Door Stop 5500mm



Aluminium Skirting and Accessories


 Part Number Description Length

1026NA Aluminium skirting 100mm Adhesive fix Natural Anodised 3600

1028NA Aluminium skirting 150mm Adhesive fix Natural Anodised 3600
ANBL10 Anodising Block 1/PK NA
64DJ K1000 Series Drilling Jig 1/PK NA
1020B Schlegel Wool Pile - Black 100m
1020G Schlegel Wool Pile - Grey 100m
1021 Semi- Acoustic Door Seal 100m

1024 Glazing Support Block 10 x 12mm 500/PK
CFP100 Self Adhesive Carpet Floor Protection Roll 100m 100m

CCS Korporate Series Ceiling Channel Corner Stakes

CSS Korporate Series Channel Straight Stakes
MSS Korporate Series Main Frame Straight Stakes
MCS Korporate Series Main Frame Corner Stakes



Powder-coating colour options: Almond Ivory, Anodic Bronze, Apo Grey Satin, Arrowhead, Berry Grey, Black Gloss, Black Matt, Black Onyx Pearl, Black Satin, Bright White, Charcoal, Charcoal Matt Pearl, Claret Satin, Cool White, Doeskin Satin, Federation Red, Hamersley Brown, Satin, Hawthorn Green, Ivory Coast, Magnolia, Notre Dame, Mother of Pearl, Olde Pewter Satin, Oyster Grey, Pearl White, Pottery Satin, Primrose, Rivergum, Roseberry Grey, Stone Beige Satin, Silver Glo Pearl, Stromboll, Transformer Grey, White Birch, White Satin.

Ready to Specify the Korporate 1000 Series for your next project?

Access specification tools or contact our Project team

Specify Now

Features of the Korporate Partition Suite

The Korporate 1000 Partition Suite is a complete centrelined office partition system designed to enhance the appearance and performance of the modern office interior. Designed for architects, builders and contractors, the system combines a consistent 36mm architectural profile with interchangeable components and 64mm steel stud framing clad with 13mm plasterboard, providing a refined, cost-effective and flexible solution from design through to construction.Profile & glazing: A consistent 36mm profile accommodates glass up to 12.38mm, keeping sightlines clean without adding bulk.

  • Modular system design: Interchangeable components simplify specification, fabrication and installation while supporting future modification and system expansion.
  • Integrated solution: Designed to coordinate seamlessly with Studform Door Sets and Kwikloc® ceiling systems for a complete interior solution.
  • Installation detailing: Corner stake provision, locating fins and clip-in glazing adaptors support faster, more consistent installation on site.
  • Finish: Aluminium profiles are available in a range of anodised and powder-coated architectural finishes to suit project requirements.
  • Design flexibility: Purpose-designed glazing adaptors, door frames, transoms, ceiling channels and accessories support a wide range of commercial partition layouts.
  • Acoustic flexibility: Designed around 64mm steel stud with two layers of 13mm plasterboard, with alternative configurations including an offset 51mm steel stud and additional plasterboard layers to support increased acoustic performance where required.
  • Finish: Radiused edges and shot blast aluminium combine for a refined appearance, ready for anodising.
  • Installation support: Drilling jigs and an optional fabrication service help contractors move faster on site.
  • Stock availability: Ex-stock in 5500mm lengths, with custom lengths available for special projects to minimise wastage.

Studform supplies everything needed to deliver a project – steel studs, plasterboard, insulation, doors and hardware. The system is constantly evolving, with new sections in development. For specific design support, get in touch with our team.
